RG-SNC Network Management System

Designed for network performance management and configuration.

Highlight Features
  • Unified Network Management
  • Professional Topology Management
  • Real-Time Performance Monitoring
  • Rich and Customized Reports
  • Proactive Alarm Notifications: Email & SMS
Sales Enquiry

Comprehensive Network Topology Information

RG-SNC displays visual topology of the network infrastructure. And all the devices are discovered through three ways: ARP table, routing table and network segment.

Topology management allows users to work on their networks topology. Many types of topology diagram are available, such as L3 global and user-defined topology diagram. In the diagram, the joining links between the devices and PCs reflects the real physical cable links. Users can hence monitor the connectivity among devices network segments, device status and link bandwidth in real-time.

Besides, users can drag device icons freely and to add or delete links & devices manually for a better displaying purpose of the physical network topology. Key link detection is another key feature of RG-SNC. The connectivity of some sensitive links can be tested periodically to make alerts before network failure happens.

The SNC offers additional features below:

Topology management: Offer strengthened topology discovery performance for Layer 2 and 3. With automatic network topology display, it supports monitoring of device status displayed by a customizable topology based on users’ needs. It also supports accurate location tracking and provides a complete list of devices, allowing users to view devices in groups or in personalized format based on the actual demands.


Topology Management

Online user info: Topology displays full details such as user name, IP address, MAC address, uplink device and its port, security status and so on. This feature can send messages to devices or take them offline, etc.

Notes: This function works in collaboration with SMP and SAM.

Network diagnosis assistant: Regular inspection on network response status to offer network administrators easy management.

Event monitoring: Married with SNMP to achieve comprehensive device monitoring. The system also has a library of 80 trap/syslog alerts as default, offering a clear picture for immediate troubleshooting.

IP/MAC/Port mapping table: The system assists users to recognize ARP attacks and analyze any IP/MAC mapping changes for early warning.

Refined Device Management

The SNC offers a wide range of advanced features to facilitate network management.

Loop inspection: Married with other Ruijie products and via the RLDP (Rogue Location Discovery Protocol), quick troubleshooting is enabled for any loop failure.

Key link inspection: Initiate link inspection from source device to target device (manual/regular automated inspection). Alerts once failure is found and locate failure node.

Actual device panel: Provide the real panel of network devices for precise information checking.

Actual Device Panel

Device configuration: Graphical configuration management. Easy to operate and minimize errors.

Extensive info viewing: Support info checking on device routing table, ARP table, etc. Built-in with device Telnet and device web configuration entrances for diversified management modes.

Asset management: Allows users to collect devices information including manufacturer, category, product model, and software & hardware version. This provides administrators a clear understanding of the network infrastructure.

Hierarchical management: Define administrators’ device management rights.

Device group management: Users can add or delete device groups manually to classify devices into different groups according to their geographical position or logical position.

Comprehensive information support: Management efficiency enhancement with detailed information available, e.g. CPU, memory, port status, routing table, MAC table, ARP table and so on. Embedded Telnet and Web configuration entries to offer multiple management modes.

Interface batch management and configuration: Interface batch operation is supported to reduce maintenance workload.

Wireless device management: Supports WLAN traffic monitor, WLAN user management and AC & AP configuration.

Wireless Management

Ruijie SNC offers the latest RG-SNC-WLAN module to achieve centralized management of wireless devices.

Topology management: Real-time topology display of wireless device operation status.


Management page: Provide global view of the wireless network in 5 seconds with customizable monitoring indicators such as out of service rate and idle AP for network optimization. Monitor the wireless network operation status via AC and AP alarm, rogue AP statistics, etc.

Wireless Device Management Page

Hotspot management: Hotspot-based statistical analysis and management on APs. Hotspot diagram visualizes full details of AP distribution, signal coverage and user count, etc.

Hotspot Management Interface

Heat map diagram: Display the APs inside the hotspots visually, as well as the number of devices connected to the APs. Clearly identify the connections between APs and ACs via graphical presentation and display the user information.

Heat Map Analysis

The SNC also supports real-time spectrum analysis including spectrum chart, duty cycle diagram and real-time FFT chart.

Spectrum chart: Real-time viewing of power level and density of each frequency range in the wireless environment.

Real-time Spectrum Analysis

Duty cycle diagram: Showing the effective signal ratio of a channel within a specific period of time, i.e. it indicates how busy the channel is.

Duty Cycle Diagram

Real-Time FFT: Capturing energy level of each frequency in the 802.11 channels.

Real-time FFT

Wireless controller management: The wireless module centrally manages all ACs by interface configuration, performance monitoring, etc.

Wireless Controller Management

FIT AP management: Device status, load management and scheduled Wi-Fi radio management. The feature supports regular switch on/off and implements AP overloading alerts.

FIT APs Switch Configuration (Scheduled Wi-Fi Radio Management)

End user management: Provide details on the number of access users, rates, user online/offline status, etc.

Real-time Online User Status

Rogue AP countermeasure: Display basic info of any rogue AP once detected. The AP is located, linked to hotspot and reflected on the hotspot diagram. Warning messages can be issued to the rogue AP.

Troubleshooting assistant: IP/MAC-based searching for end device, authentication user, AP, AC and rogue AP.

IP Surveillance

●Low-threshold Bandwidth Monitoring

The RG-SNC provides advanced low-threshold bandwidth management feature which can monitor the transmitted bandwidth of each IP camera for fault management purpose. When video is being recorded in the IP camera, a minimum amount of bandwidth is required for data streaming over IP network to the NVR server. This feature allows users or administrators to configure the minimum threshold bandwidth for each of the IP cameras and NVR applications. When there is an error or the IP camera recording function is not operating as normal, the low threshold rule with key link detection of low bandwidth will be triggered and the RG-SNC will provide proactive alert and alarm generation. This will facilitate the administrator to find the root cause easily with the unified management software.

This feature is mainly designed for environments and situations that require 24-hour video recording for high security purpose. CCTV surveillance is critical to a lot of industry such as large logistic sector, business banking environment and public sector which requires high security with video recording used as criminal evidence in court.

Low-threshold Bandwidth Monitoring

●Remote Power Management

The RG-SNC supports remote power management such as power on/off and power restart for wireless APs, IP cameras and other PoE-powered devices via the topology management view which facilitates operation and maintenance support. The RG-SNC enables remote power control of IP cameras instead of operating on the NVR. When the IP camera is not functioning properly, identify which device it is connected to and select the port which needs to restart the PoE power. The RG-SNC can control the PoE power in the switch to turn off or restart the device.

Camera Power Restart Operation

Configuration Management

The SNC supports various configuration management functions, such as regular backup and recovery of device configuration, software management and software issue schedule management. The SNC supports various configurations managing functions including:

Configuration snapshot: The system supports customized collection of device configuration for backup to ensure painless recovery upon failure.

Configuration comparison: Automatically compare the latest configuration details with the previous after backup is completed. Network administrators can acquire any changes easily for risk management.

Unified Management of System Software

Device software statistics: Provide statistics and details on device model and software version for synchronization.

Device software batch assignment: Synchronize software updates for all the devices in the network with details provided.

Performance Management

Real-time performance monitoring provides better understanding of network infrastructure, thus facilitates network management. This function includes the following features:

Real-time performance curve display

TOP-N performance statistic

Performance monitoring indicator setting

Performance threshold self-define

Historical performance query

Device Performance Display

Alarm Management

The SNC supports the following alert features during operation:

Real Time alarm monitoring

Self-define alarm rule & time

Voice/email/SMS alarm notification(3rd-party SMS modem required for SMS alarm)

Historical alarm query

Trap & syslog event monitoring

Report & Log Management

The Ruijie SNC assists administrators on network troubleshooting and problems locating to achieve desired outcome. The report & log management function includes the following features:

Alarm report

Assets report

Security log

Operation log

Report export

Alarm Report Display

Report Management

Server Management

Ruijie RG-SNC retrieves details and monitor devices in the server using the SNMP, which the monitored devices are required to open. The function supports monitoring on the following:

CPU operation efficiency

Internal storage usage efficiency

Port traffic rate

Server operation status via SNMP or PING

System Management

The SNC enables administrators to manage the network devices according to their administrative privileges. This function includes the following features:

Device assets management

System parameter setting

Email server configuration

Configuration for software update FTP server

SAM, SMP server configuration

Administrator management

Role management

Password setting

Concurrent login management

Schedule operation log

Device software report

Software update tips

Syslog overdue settings

Favorites menu

Trap forward management

Event forwarding management



Product Specifications



RG-SNC Basic Component

B/S Architecture

Deployed based on pure B/S architecture. No client installation is required for users. Enable system access using any standard browsers.

System Management

Support system restart and shutdown using web browser; Monitor server CPU, memory and network card status; Support retrieval of system operation logs via the web page.

License Management

Support file licensing mode.

System Integration

Support integration of authentication-free feature of the network control interface with customer system.

Support forwarding of network management alert, syslog, trap to customer system.

Support integration with web services, or network management properties, alerts, performance data.

Unified Wired and Wireless Management

Support unified wired and wireless management on devices such as routers, switches, firewalls and WLAN by modularization.

IP Surveillance

Support low-threshold bandwidth monitoring, remote power management and flexible icon management.

Component Scalability

Support wireless networking for the ease of future unified management and surveillance on wired and wireless devices.

Device Management

Support a variety of device management features. Include a good presentation and basic operating features for creating, deleting or editing device interfaces and data.

Support batch software upgrade for multiple devices.

Support a graphical presentation of the actual physical boards, line cards and ports. Support operation directly on the page.

Support auto software upgrade checking. Support batch software upgrade.

Support management based on hierarchy and categorization. Enable users to set status of one device or multiple devices to be read-only, writable or hidden. For hidden devices, markings are required to be shown on topology.

Support editing of device information such as organization name, purchase date, warranty validity, etc.

Device Configuration Management

Support auto retrieval of configuration files on a regular basis and synchronization to management server. Support comparison of the collected data with the previous configuration files. Notify the administrator via email if any difference is found.

Topology Management

Support auto discovery of Layer 2 and Layer 3 network devices. Support auto topology formation.

Support discovery of WAN link topology. Support adding virtual nodes such as "building", "cloud", etc.

Support viewing of a customized topology by a designated IP range or through chosen devices. In every such topology diagram, only matching devices are shown.

Support auto discovery of routing topology, showing routing relation among devices in the system network layer.

Support export of the current topology.

Support dynamically update network topology based on device and link status data collected in real time.

Support dual-link STP detection. The topology shows real-time status of both links respectively.

Support topology display in full screen.

Under the full screen mode, proactively send topology alerts in an animated presentation.

In the event of operating status changes or alerts triggered, the relative nodes in the topology can be highlighted in real time.

Support VSU topology and show the many-to-one virtualization in the topology in real time. Support direct viewing of links and status of multiple device members on the topology.

Support image upload for background customization.

Support image upload for node icon customization.

Support traffic topology of the Weather Map mode.

Real-time Alert

The product should be built-in with a variety of common alert categories. Support alert category customization based on the actual demand whenever necessary. Provide a minimum of 10 common syslog alert customization lists.

The product should be built-in with a variety of common alert categories. Support alert category customization based on the actual demand whenever necessary. Provide a minimum of 50 pre-defined trap alert customization lists.

Support setting performance indicator threshold as general, important or very important. When the indicator exceeds the threshold, respective alert will be sent based on the threshold value.

Support traffic lower limit alert. When the traffic is lower than the designated threshold, alert will be sent.

Support maintenance schedule for designated devices. Within such period maintenance, no alert will be sent.

Key Link Detection

Support intelligent real-time detection for key links. Upon status changes, quickly locate failure. Support multiple alert modes to notify the administrator to resume network service as soon as possible.

Report Management

Customize task for long-term surveillance of the network performance. Support report generation on a real-time or periodic basis.

Support report creation, search, editing, deletion. Support report online viewing, import/export, etc. Support periodic export and regular publishing.

Support history report search.

Interface Mapping Management

Support regular collection of user devices IP, MAC, port mapping table. When there are abnormalities found in the mapping table, alert administrator as an event immediately.

Integration of Topology and User Information

To protect customer's early investment, support registration integration with SAM/SMP. Support searching of online user table including user name, IP address, MAC address, etc.


The product should support standard SNMP MIP management base. Support management on mainstream vendor standard MIB device.


The product should be compliant with the related rules under Administration of Software Products Regulation.

With national software copyright registration certificate.

RG-SNC WLAN Component

Topology Management

Support viewing of all wired and wireless devices on one single topology.

Surveillance Statistics

Support accessibility and alert statistics for all wireless ACs and APs.

Support user trend statistics for the whole network, hotspots, single AC and APs. Support online user statistics for hotspots, single AC and APs.

Support logout rate statistics for the whole network, hotspots and single AP. Support setting a time range for logout rate statistics. Support viewing of Top N logout rate statistics.

Support idle AP statistics for the whole network. Support viewing of Top N idle APs on a daily or monthly basis.

Support uplink and downlink rate statistics/Top N viewing for all hotspots and APs. Support trend statistics for single hotspot, AP uplink and downlink rates.

Support surveillance indicator customization.

Device Management

Support viewing of the following information in AP: wireless radio table, device information, originating AC and hotspot, SSID, alert statistics, etc.

Support statistics of AP online user trend, bandwidth utilization trend, CPU/memory utilization trend and STA association failure causes.

Support radio on/off setting of AP.

Support manually adding, deleting and auto discovery of AC.

Support connecting AC to Web network control and Telnet management.

Support viewing of the following information in AC: device panel, device information, device status, management AP, SSID and alert statistics.

Support AC statistics on current user trend, bandwidth utilization trend and CPU/memory performance trend.

Wireless User Management

Support viewing of wireless user MAC, IP, online status, online duration, uplink/downlink rates, signal strength and device type.

Support viewing of user online/offline records including time of occurrence, action, user IP, WLAN ID, SSID, associated AP, originating AC, etc.

Support real-time surveillance on designated devices for uplink/downlink traffic trend and signal strength. Data update frequency <=5s.

Support designating several terminals as key end devices with operation quality surveillance. Issue alerts when packet retransmission rate exceeds the designated threshold.
Issue alerts when abnormal behavior is found in the key end devices. Such events include offline, association/online failure, etc.

Support viewing of end device statistical graphs of designated user group (hotspot). Minimum requirement: present the graphs in terms of band (2.4G, 5G), connection protocols (802.11a/ 802.11b/ 802.11g/ 802.11n/802.11ac/802.11ax).

Spectrum Analysis

Support >=8 spectrum analysis: current interference table, spectrum diagram, real-time FFT diagram, FFT occupation ratio diagram, spectrum density diagram, channel occupation ratio diagram, channel occupation ratio trend diagram and power trend diagram.

Device Configuration Management

Support configuration of AC system attribute, WLAN, security, interface, trap/syslog servers, etc.

Support synchronization of AC blacklist.

Wireless Tracking

Support tracking of end device, authentication user, AP, AC, rogue AP based on IP, MAC, login user name, real user name, device name, SSID, AP location or hotspot name.

Rogue AP Management

Support rogue AP table including rogue AP BSSID, SSID, channel, signal strength, vendor, finder AP and its location, single AP mode, countermeasure status, etc.

Support AP operating mode and rogue AP countermeasure status statistics.

Support graphical configuration of AP operating mode (graphical guidelines for AP operating mode configuration).

Support setting of blacklist and whitelist.

Hotspot Heat Map Management

Support import, export and manual editing of hotspot information.

Support existing APs management based on hotspots. Support statistics of SSID associated with hotspot, logout rate, associated user count and uplink/downlink rates.

Support floor plan import in .jpg, .png or .gif format. Support setting AP location on the floor plan and viewing of AP coordinates.

Support setting different kinds of obstacles. Support setting AP height and deployment scenario.

Support viewing of AP information, AP user information on heat map and adjusting AP channel.

Support heat map generation based on signal strength, rate, channel conflict (2.4G/5GHz).

Alert Management

The product should be built-in with a variety of wireless alert categories. Support alert category customization based on the actual demand whenever necessary. Provide a minimum of 10 common syslog alert customization lists.

The product should be built-in with a variety of wireless alert categories. Support alert category customization based on the actual demand whenever necessary. Provide a minimum of 15 pre-defined trap alert customization lists.

Hierarchical Management

Support AC, hotspot and SSID management based on hierarchy and categorization.

Report Management

Customize task for long-term surveillance of the network performance. Support report generation on a real-time or periodic basis.

Support report creation, search, editing and deletion. Support report online viewing, import/export, etc. Support periodic export and regular publishing.

Support history report search.

Support report data filtering based on AC, hotspot or SSID.

Integration of Topology and User Information

To protect customer's early investment, support registration integration with SAM/SMP. Support searching of online user table including user name, IP address, MAC address, etc.


The product should support standard SNMP MIP management base. Support management on mainstream vendor standard MIB device.


The product should be compliant with the related rules under Administration of Software Products Regulation.

With national software copyright registration certificate.

System Requirements

Hardware Platform Requirement


Quad-core, each core at 2GHz or above (recommended)


4G or above


160G or above

Network Interface Adapter

100Mbps or above

Operating System and Database

Operation System

Linux Centos 6.6 64bit


MariaDB-5.5.54 64bit



Show More
Resources All Resources
Learn about Products or Solutions
Software and Configuration
Order Information




Basic component of Smart Network Commander

(Node license sold separately)


Topology management component of Smart Network Commander


WLAN component of Smart Network Commander



SNC license for 15 universal nodes


SNC license for 25 nodes


SNC license for 50 nodes


SNC license for 100 nodes


SNC license for 200 nodes


SNC license for 500 nodes


SNC license for 1000 nodes


SNC-WLAN license for 50 FIT APs


SNC-WLAN license for 100 FIT APs


SNC-WLAN license for 200 FIT APs


SNC-WLAN license for 500 FIT APs


SNC-WLAN license for 1000 FIT APs


SNC-WLAN license for 2000 FIT APs


SNC-WLAN license for 5000 FIT APs



Show More
How do you rate your search experience on this website from 1 to 10?
Very Difficult
Very Easy
If you would like to offer more comment, please type in the textbox below, that would be helpful for the improvement of the search engine.
Thank you for your feedback!

Ruijie Networks websites use cookies to deliver and improve the website experience.

See our cookie policy for further details on how we use cookies and how to change your cookie settings.

Cookie Manager

When you visit any website, the website will store or retrieve the information on your browser. This process is mostly in the form of cookies. Such information may involve your personal information, preferences or equipment, and is mainly used to enable the website to provide services in accordance with your expectations. Such information usually does not directly identify your personal information, but it can provide you with a more personalized network experience. We fully respect your privacy, so you can choose not to allow certain types of cookies. You only need to click on the names of different cookie categories to learn more and change the default settings. However, blocking certain types of cookies may affect your website experience and the services we can provide you.

  • Performance cookies

    Through this type of cookie, we can count website visits and traffic sources in order to evaluate and improve the performance of our website. This type of cookie can also help us understand the popularity of the page and the activity of visitors on the site. All information collected by such cookies will be aggregated to ensure the anonymity of the information. If you do not allow such cookies, we will have no way of knowing when you visited our website, and we will not be able to monitor website performance.

  • Essential cookies

    This type of cookie is necessary for the normal operation of the website and cannot be turned off in our system. Usually, they are only set for the actions you do, which are equivalent to service requests, such as setting your privacy preferences, logging in, or filling out forms. You can set your browser to block or remind you of such cookies, but certain functions of the website will not be available. Such cookies do not store any personally identifiable information.

Accept All

View Cookie Policy Details

Contact Us

Contact Us

How can we help you?

Contact Us

Get an Order help

Contact Us

Get a tech support
